Hybrid PBX N824

Yeastar N824 is a fully-fledged PBX that delivers advanced communications features of a large system to small office. Yeastar N824 maximizes cost-effectiveness with 8 CO lines, 24 analog extensions, 8 SIP extensions, and 8 SIP trunks. It provides all the features you need in a plug-and-play box, perfectly future proofing your telecom investment.

N824 voip system attributes
hybrid pbx n824

PBX for Small Business

N824 is designed to deliver advanced communications features of a large system to small office. It provides an easy to afford and easy to use system for small business to maximize cost-effectiveness.

  • 8 CO Lines
  • 24 Analog Extensions
  • SIP extensions and trunks

Powerful Built-in Features

Enjoy the convenience and efficiency that N824 brings without extra licensing fees.

  • Voicemail Messages
  • Multi-level Auto-attendant
  • Call Recording Capability
  • Timed Condition Routing
  • No Licensing Fees
hybrid pbx
plug and play

Plug-and-play Installation

N824 is ready to play out of the box with plug-and-play facility. It is extremely easy to install without requiring engineering background or network knowledge. In rare circumstances when configuration is needed, the user-friendly Web interface works easy and intuitive.

CO Lines 8
Analog Extensions 24
RJ21 Connectors 1 for FXS and 1 for FXO
SIP Extensions 8
SIP Trunks 8
Network Interfaces 1 10/100Mbps
Protocol SIP (RFC3261)
Transport UDP, TCP, TLS, SRTP
DTMF RFC4733, SIP INFO, In-band
Codec G.711 (a-law, u-law), G.722, G.726, G.729 A/B, GSM, iLBC
Console Port 1
SD Card Slot 1
Dimensions 440 mm × 250 mm × 44 mm
Weight 1.5 kg
Power AC 100-240V (12V, 5.5A)
Operation Range/td> 0°C to 40°C, 32°F to 104°F
Storage Range -20°C to 65°C, -4°F to 149°F
Humidity 10-90% non-condensing

Attended Transfer Automated Attendant (IVR)
Automatic Upgrade Backup and Restore
Blind Transfer Busy Camp-on
Call Barge-in Call Detail Records
Call Duration Restriction Call Forwarding (All, Busy, No Answer)
Call Hold Caller ID
Call Parking Call Pickup
Call Recording Call Report
Call Report Export Call Waiting
Conferencing Custom Prompts
Do Not Disturb (DND) Fax to Email
Follow Me Hotline
Intercom Last Caller Routing
Music on Hold Music on Transfer
One Touch Record Queues
Ring Group Seize a Line
Speed Dial System Logs
T.30 & T.38 Fax Time Condition Routing
Timed Reminder Voicemail
Voicemail Forwarding Voicemail to Email

Demo
N824 demo on a live website. Login in as an administrator to experience the intuitive Web GUI and explore the powerful features of N824.
UserName: admin
password: password
